How To Install and Auxiliary Outboard Engine

Considering an outboard kicker? Here's how to install it.

How To Install and Auxiliary Outboard Engine

Tip: If the transom is angled in such a way that the kicker cannot be properly trimmed with the anti-ventilation plate parallel to the waterline, fashion a wedge from hardwood or King Starboard lumber to place the motor in the correct operating position.

Tim Barker

Auxiliary outboard motors serve powerboaters in two primary roles: 1) as an emergency get-home motor in case the big engine conks out, and 2) for alternate propulsion when the main engine moves the boat too fast to effectively slow-troll. Anglers in the Pacific Northwest and elsewhere find “kickers,” as they’re called, extremely useful when slow-trolling for salmon and trout. Sailboaters also use kickers when sailing is impractical.

One way to carry and use a kicker is with an auxiliary outboard bracket, such as the Garelick model 71091, which is built especially for heavier, high-torque four-stroke motors. This model can handle engine weights up to 175 pounds and as much as 25 hp, allowing you to smoothly raise and lower the motor with one hand.

This bracket features black-satin anodized aluminum construction with a 2-inch-thick black poly mounting board and offers four vertical running positions to accommodate the boat load and water conditions. Stainless-steel hardware offers durability. We installed this bracket on the transom of a sterndrive-powered boat.

Skill Level: 3 of 5
Finish Time: Approx. 4 hours

Tools and Supplies

  • Garelick model 71091 aluminum motor bracket for four-stroke motors ($316.18, iboats.com)
  • Drill motor and 3/8-inch drill bit
  • Sheet of 1/4-inch aluminum to fashion a backing plate ($4.47/6-by-18-inch sheet, homedepot.com)
  • 3M 4200 marine sealant/adhesive ($27.99/10 oz. cartridge, westmarine.com)
  • Four 3/8-inch stainless-steel hex-head bolts, fender washers and locknuts
  • Stainless-steel bolts, washers and locknuts for mounting the outboard
  • Socket and box/open-end wrench sets
  • Tape measure
  • Wooden stick
  • Pencil marker, tape
How To Install and Auxiliary Outboard Engine

Horizontal Measure

Tim Barker

Horizontal Measure
Choose the most appropriate side of the transom. Since the outboard tiller is usually on the port side of the motor, most kickers are mounted on the starboard-side of the transom to facilitate easier tiller steering and throttle control while slow-trolling or putting home. Determine a position on the transom far enough to the side so that the kicker will not interfere with the operation or swing of the sterndrive or main outboard and vice versa. Make sure the position allows for through-bolting of the motor bracket.

How To Install and Auxiliary Outboard Engine

Vertical Measure

Tim Barker

Vertical Measure
Measure the distance on your kicker between the anti-ventilation plate and upper inside edge of the outboard clamp. Subtract 2 inches from this length, then add 15 1/2 inches (vertical travel for the model 71091). Cut a wooden stick to this length and tape it so the top is even with the top of the poly mounting board. Place the mounting flange on the transom so that the center of the stick is 1 inch above the bottom of the hull (for powerboat installation) and mark the location for the mounting flange on the transom.

How To Install and Auxiliary Outboard Engine

Mark and Drill

Tim Barker

Mark and Drill
Make sure the top of the mounting flange is square with the upper edge of the transom. Using the flange as a template, mark the four outside hole locations. Be sure you have access to the backside of the transom for through-bolting. If not, choose one of the alternate bolt holes in the bracket (there are three holes in each quadrant). Check for interference from hoses and wires on the inside of the transom before drilling. Drill the four 3/8-inch holes, each at a right angle to the transom.

How To Install and Auxiliary Outboard Engine

Install the Bracket

Tim Barker

Install the Bracket
Mounting hardware is not supplied. Buy four 3/8-inch-diameter stainless-steel mounting bolts, long enough to reach through the transom with enough room to accept fender washers and locknuts. Garelick also recommends using a backing plate inside the transom. Coat the inside of the mounting flange and backing plate with a marine sealant such as 3M 4200 and squeeze some in each transom mounting hole. Bolt the bracket securely to the transom (you will need a buddy to help you tighten the bolts).

How To Install and Auxiliary Outboard Engine

Mount the Motor

Tim Barker

Mount the Motor
Many small outboards come with clamp brackets, but these can vibrate loose over time, risking loss of your kicker. So don’t rely solely on the clamps. Secure the motor by using the lower mounting holes on the outboard bracket to through-bolt the motor. The Garelick mounting pad comes with mounting holes for this purpose. Use stainless-steel bolts appropriately sized to fit the outboard mounting holes. Secure the bolts with fender washers and locknuts. Garelick recommends against trailering with a motor on the bracket.
