Tips for Repowering Older Boats

The challenges of outfitting an older boat with fresh power.

Today’s four-stroke outboards are more reliable than ever before with fly-by-wire controls and onboard sensors that maximize performance and efficiency. But, as my Roman forebears used to say, caveat emptor: The four-stroke solution is not the singular magical fix ideal for repowering all boats. What boats are we talking about? What are the challenges? What should you do before repowering? Here’s the scoop.

The first generation of four-strokes all had one thing in common: They were heavy. When you added all of those extra four-stroke parts, like an oil sump, valve train, etc., the engines definitely increased both their mass and weight. For example, the Yamaha F200/F225 four-strokes weighed more than 600 pounds (and they still do today at 608 pounds). A 200 hp two-stroke engine of that era might have weighed 425 pounds.

Tips for Repowering Older Boats

The 2002 model year is noted for one event that changed the way that outboard boats were designed and powered: Yamaha's F200/F225 V-6 hit the market.

Yamaha

In 2014 just about any maker’s 200 hp V-6 costs upwards of $20,000 installed, depending on your gauge package, controls, installation, etc. Although it doesn’t burn pricey two-stroke outboard oil, it does require additional maintenance, like oil changes every 100 hours of use and valve adjustments at every 300 to 400 hours, expenses that don’t impact two-stroke owners. (For a complete breakdown of the cost of outboard ownership, visit boatingmag.com/boatinglab-outboards.) Plus, four-strokes that deadhead half of their cylinders with every turn of the crankshaft need more cylinder mass to compete with the prop-shaft sea horses generated by two-stroke power plants that are firing all of their cylinders with every rotation of the crank. If you are repowering a newer boat, going with a four-stroke repower is probably nothing to worry about. But when considering a new outboard for a pre-2002 vessel, there is a concern regarding which solution will work best, since these boats likely weren’t designed with the requisite buoyancy aft that is needed to keep cockpit scuppers above the waterline with added weight on the transom.

Tips for Repowering Older Boats

Repower Problems
Pick the wrong engine to repower your boat, and you could be in for these troubles. Always contact the boatbuilder prior to repowering.

1. Loss of ability to self-bail
2. Possible swamping with open transoms
3. Porpoising
4. Slow planing
5. Poor visibility forward

Boating Magazine

If you have to stick with a two-stroke due to either weight or mass, Evinrude E-TEC and Mercury OptiMax two-stroke direct-injection V-6s should do the job. Sure, you’ll have to buy some two-stroke oil in bulk, which adds to the cost-per-mile of boat operation, but you’ll never have to do an oil change, swap an oil filter or adjust valves, all of which add to annual operating costs.

Tips for Repowering Older Boats

Scuppers above the waterline ensure drainage.

Wide chines are one way to help float heavier power.

Brackets with more immersion provide more buoyancy.

Boating Magazine

Also, four-strokes are losing weight, which should help when repowering an older legacy boat. Yamaha recently introduced an in-line 2.8-liter F200 that tips the scales at a svelte 487 pounds, which is actually lighter than a two-stroke 3.0-liter V-6 OptiMax. Not to be outdone by the competition, Merc introduced its own next-gen four-stroke last year, a 150 hp — an in-line-4 with a 3.0-liter block that has room to grow. It tips the scale at 465 pounds. The valves on this new Merc 150 never need adjustment, which will lower operating costs.

Tips for Repowering Older Boats

Heavy Hitters
Weight and torque ramped up when Honda and Yamaha debuted new four-stroke outboards.

2002
Boaters were ready but some boats were not.
Two-strokes by Evinrude, Mercury thrive.

2014
Four-stroke engines are lighter.
Boats are designed for new engines.

Boating Magazine

If you need to focus on outboards in the 225 hp to 300 hp range, Yamaha’s new-wave Offshore series (225, 250, 300 hp) provides the power and torque of a 4.2-liter V-6 block but lowers the overall weight of these triplets to an incredible 562 pounds. This mechanical miracle was accomplished by taking out the six-pack of steel-cylinder liners, which opened up the bore volume, which was then plasma-infused to provide a superslick surface to reduce piston-ring friction. I have personally tested all three of these new lightweight four-stroke outboards in single, twin and triple configurations on both new and older boats, and they are indeed next-generation masterpieces that will afford you with some viable repowering options.

Hopefully some of the lessons I’ve shared about repowering older boats will help you when it’s time to repower yours. To see a chart of horsepower and transom weights of outboard repowering options, visit boatingmag.com/repower-options.

What Some Experts Say About...
Problems Associated with Adding Weight on the Transom

To get some science on the subject, I contacted respected top-tier builders and a naval architect to get their spin on the challenges of repowering “legacy” boats that were built prior to 2002.

Tips for Repowering Older Boats

David Neese: Vice president of engineering, Grady-White Boats

Boating Magazine

David Neese
Vice president of engineering, Grady-White Boats, Greenville, North Carolina

"Back in early 2001, by fortunate planning, a redesign of our SeaV2 hulls coincided with the introduction of the Yamaha F225 outboards in 2002, and the newer Gradys had no trouble supporting the weight and torque of the four-stroke power plants,” he said. “When repowering older pre-2001 Grady-White boats, many of our bracket designs and conventional transoms will successfully support the newer four-strokes, but it depends on the application.” In addition to the deadrise and chine width of the boat to be repowered, the weight and size of the boat should also be considered. Often the added weight on a larger boat will not make a significant difference if the boat was well designed from the beginning. Adding 200 pounds to an 8,000-pound boat adds 2.5 percent of the overall boat weight, while adding the same 200 pounds to a 15,000-pound boat adds only 1.3 percent.

“From a structural standpoint, sound construction is sound construction regardless of the materials used,” Neese said. “A well-built boat will be somewhat overbuilt structurally, but when you are talking about older boats, you reach a point where the new engines can dish out more than the old hulls with some miles under their transoms can take.”

Tips for Repowering Older Boats

Joan Maxwell: President, Regulator Marine

Boating Magazine

Joan Maxwell
President, Regulator Marine, Edenton, North Carolina

“The first thing that a customer should do prior to repowering a boat is to contact the manufacturer of the boat and provide the boat’s HIN [hull identification number]. There really isn’t a quick answer on whether every model in the line or even every boat built of a specific model could be safely repowered with newer four-stroke engines,” Maxwell explained.

“We at Regulator Marine have built boats that were powered by both transom- and bracket-mounted outboard engines. The bracket could support the weight of the existing engines, but then the ­game-changing 225 four-strokes came along and we had to completely redesign the bracket.

“Customers should call and ask us before just going out and slapping a new pair of engines on their boat,” she said. The Yamaha F350 V-8, for example, has a lot of low-end torque. However, the engine could not safely be placed on an older Regulator 23 or 24, even though the boat may have been rated for the horsepower, because the transom simply was not built for that kind of weight and torque. “As the four-stroke engines have gotten larger and ‘torquier,’ our transom laminate structures have been redesigned to support the change in these engines,” Maxwell said.

Tips for Repowering Older Boats

Lou Codega: Naval architect, engineer, designer for production and custom boatbuilders

Boating Magazine

Lou Codega
Naval architect, engineer, designer for production and custom boatbuilders

“When I design a hull, I select a location for the center of gravity forward of the transom early on and arrange the interior of the boat accordingly. This center gives me the best combination of fuel efficiency at cruise speed and the highest top speed, taking into account how the boat will be used. Second, handling problems can occur if the center strays too far from the sweet spot. Too far aft leads to porpoising; too far forward can cause bow steering, a wet ride and serious instabilities.

“None of this bodes well for repowering with engines that are substantially different in weight or horsepower. Weight added so far aft in the boat makes a substantial change to the original center of gravity. To make matters worse, the change in weight and horsepower suggests a new center of gravity to better suit the repowered boat.

“When I’ve redesigned a boat for different power, I’ve found that other changes are always needed. These can be as minor as a change to the bracket flotation, or a major redistribution of weights. Obviously, this complicates the project far beyond simply swapping engines, controls and fuel fittings. It is far simpler to choose an engine package that closely matches the power and weight originally installed.”

Tips for Repowering Older Boats

Seven Marine's 557 can provide another repowering option for older boats, those designed and built before about 2002.

Seven Marine

Single-Engine Option?
Have big, superpowerful new outboards changed the repower game by allowing multiengine boats to be propelled by just one engine? It's a theory that's thrown around - here, our Editor-in-Chief opines on the viability of that theory.

Big, powerful outboards like the 557 hp Seven Marine 557 and the 350 hp Mercury Verado and Yamaha F350 can provide another repowering option for older boats, those designed and built before about 2002. This is particularly true if the boat in question was originally powered by multiple outboard engines. Can is the operative word.

For example, if your boat is rated for two outboards and 400 hp, you might consider installing a single 350 hp outboard. Doing so would net you somewhat less horsepower than the original twin installation. But with only one gear case creating drag in the water, compared to two gear cases creating drag, comparable speed and performance would likely be attained. Additionally, the price and complexity of the installation for one big single engine can cost less than those for multiple engines, since fewer gauges, wiring harnesses and propellers are required, and controls and steering equipment are simpler.

So why doesn’t everyone do this?

There are several reasons, and the first is that these monstrously powered outboards deliver enormous amounts of torque, possibly more than your older boat’s transom can handle. Furthermore, unlike with multiple engine installations, all the power and torque transmitted to the boat is concentrated at one spot on the transom instead of spread across multiple locations on the transom.

Safety concerns are another reason why swapping out two or more lower-powered outboards for a big single engine isn’t common. As trustworthy as outboard motors have become — they may now rank as the most reliable propulsion type in the history of marine transport — boaters who cruise far from shore still rely on the redundant safety of multiple engines: Should one break down, the other(s) can get you home.

Then there is dockside maneuverability. While outboards do not respond like inboards — due in part to torque, propeller size and a pivot point farther aft — a multiengine boat handles close quarters better than a single-engine boat. Multiple engines also allow boaters to avail themselves of the convenience (and, admit it, coolness) of the joystick control systems now available for outboards.

Swapping multiple engines for one big engine is a great idea. But not every boat is up to the task. -Kevin Falvey
